Honda HR-V: DTC B1C68, Driver's Heater Not Heating
.png)
DTC (Front Seat Heater Control Unit)
NOTE :
- If you are troubleshooting multiple DTCs, be sure to follow the
instructions in B-CAN System Diagnosis
Test Mode A - Refer to: Body Electrical Troubleshooting - B-CAN System
Diagnosis Test Mode A -
Initial Communication and DTC Checks.
- The seat heater control unit does not turn on the seat heater until the
seat core temperature is 85 degrees
or less. Make sure the seat core temperature is below 85 degrees before
troubleshooting.
1. Problem verification:
- Clear the DTCs with the HDS.
Clear DTCs
- Turn the vehicle to the OFF (LOCK) mode and then the ON mode.
- Check for DTCs with the HDS.
.png)
Is DTC B1C68 indicated?
YES
Go to step 2.
NO
Intermittent failure, the system is OK at this time. Check for loose or poor
connections.
2. DTC check:
Check for DTCs with the HDS.
.png)
Are DTCs B1C55, B1C56, B1C60, and/or B1C61 indicated?
YES
Go to DTC B1C55 troubleshooting.
YES
Go to DTC B1C56 troubleshooting.
YES
Go to DTC B1C60 troubleshooting.
YES
Go to DTC B1C61 troubleshooting.
NO
Replace the driver's seat cushion heater.
