Honda HR-V: DTC Troubleshooting C0031-62, C0034-62, C0037-62, C300a-62: Wheel Speed Sensor Malfunction

NOTE: Before you troubleshoot, review the how to troubleshoot the electric parking brake system.

1. Problem verification:

1. Turn the vehicle to the ON mode.
2. Clear the DTC with the HDS.
3. Turn the vehicle to the OFF (LOCK) mode, then to the ON mode.
4. Check for DTCs with the HDS.

Is DTC C0031-62, C0034-62, C0037-62, or C003A-62 indicated?

YES

The failure is duplicated. Go to VSA system troubleshooting.

NO

Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting. If the freeze data/on-board snapshot of this DTC is recorded, try to reproduce the failure under the same conditions with the Freeze data/on-board snapshot.

DTC TROUBLESHOOTING C0062-1C: LONGITUDINAL ACCELERATION SENSOR (INSIDE OF ELECTRIC PARKING BRAKE CONTROL UNIT) RANGE/PERFORMANCE PROBLEM

NOTE:

• Before you troubleshoot, review the how to troubleshoot the electric parking brake system.
• Before troubleshooting, check the electric parking brake control unit for proper mounting. If not properly installed the electric parking brake control unit may set this code.

1. Problem verification:

1. Turn the vehicle to the ON mode.
2. Clear the DTC with the HDS.
3. Turn the vehicle to the OFF (LOCK) mode, then start the engine.
4. Accelerate the vehicle, then stop the vehicle.

NOTE: Drive the vehicle on the road, not on a lift.

5. Check for DTCs with the HDS.

Is DTC C0062-1C indicated?

YES

The failure is duplicated. Go to step 2.

NO

Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting. If the freeze data/on-board snapshot of this DTC is recorded, try to reproduce the failure under the same conditions with the Freeze data/on-board snapshot.

2. Electric parking brake control unit check (update or substitution):

1. Update the electric parking brake control unit if it does not have the latest software. If the unit already has the latest software, substitute a known-good electric parking brake control unit.
2. Turn the vehicle to the OFF (LOCK) mode, then start the engine.
3. Accelerate the vehicle, then stop the vehicle.

NOTE: Drive the vehicle on the road, not on a lift.

4. Check for DTCs with the HDS.

Is DTC C0062-1C indicated?

YES

Check for loose terminals and poor connections in the electric parking brake control unit 30P connector.

If the electric parking brake control unit was updated, substitute a known-good electric parking brake control unit and recheck. If the electric parking brake control unit was substituted and the symptom/indication is still present, replace the original electric parking brake control unit.

NO

If the electric parking brake control unit was updated, troubleshooting is complete. If the electric parking brake control unit was substituted, replace the original electric parking brake control unit.

DTC TROUBLESHOOTING C0062-54: LONGITUDINAL ACCELERATION SENSOR (INSIDE OF ELECTRIC PARKING BRAKE CONTROL UNIT) NEUTRAL POSITION NOT LEARNED

NOTE: Before you troubleshoot, review the how to troubleshoot the electric parking brake system.

1. Problem verification:

1. Turn the vehicle to the ON mode.
2. Clear the DTC with the HDS.
3. Turn the vehicle to the OFF (LOCK) mode, then to the ON mode.
4. Check for DTCs with the HDS.

Is DTC C0062-54 indicated?

YES

The failure is duplicated. Park the vehicle on a flat and level surface, then do the longitudinal acceleration sensor neutral position memorization.

NO

Intermittent failure, the system is OK at this time. Refer to intermittent failures troubleshooting. If the freeze data/on-board snapshot of this DTC is recorded, try to reproduce the failure under the same conditions with the Freeze data/on-board snapshot.
